Icon

S2 Secondary Shocks System - Stage 2 Kit

2016-2023 Toyota Tacoma

$2,362.35 $2,499.90

Starting at $148/mo or 0% APR with Affirm. See if you qualify

In Stock

Estimated Delivery in 3-7 business days

Icon

S2 Secondary Shocks System - Stage 2 Kit

2016-2023 Toyota Tacoma

$2,362.35 $2,499.90

Starting at $148/mo or 0% APR with Affirm. See if you qualify

In Stock

Estimated Delivery in 3-7 business days

Authorized dealer

Free shipping within the lower 48 United States

Brand new parts with warranty coverage

Free 30-day return and exchange on qualifying orders

Got Questions?

Our experts are here to help!

Chat now Request a call back

Part Numbers & Details

Specifications

Part Number	Lift/Lowered	Position	Item	Quantity
K53126	0-2.75" Lift	Front	S2 Secondary Shock System - Stage 2	1

Overview

The ICON Vehicle Dynamics S2 Secondary Shock System redefines the off-road capability of the 2016-UP Toyota Tacoma by allowing for the installation of a secondary shock to an existing ICON coilover setup. The addition of a secondary 2.5 Series or Omega Bypass shock means rougher terrain and larger off-road obstacles can be overcome with confidence as the damping ability of the vehicle's suspension is effectively doubled. As opposed to overly complicated and expensive long travel kits, the ICON S2 System is an affordable upgrade that drastically increases off-road performance, is easy to install, and has a modular design that allows 2016-UP Toyota Tacoma owners to upgrade in steps or all at once.

The S2 Secondary Shock System utilizes the factory lower control arms and maintains OE track width while a combination of a billet aluminum shock tower adapters, fabricated shock hoops, and steel skidplates (with incorporated shock mounts) make for a straightforward install with the exceptional build quality you would expect from an ICON Vehicle Dynamics product. The system was designed to eliminate the need for any major alteration of the vehicle'rame or any other factory suspension components, and the components are 100% removable in case the system is to be installed on another vehicle. The modular design of the S2 kit also allows for standalone installation of the skid plates, which provides the added benefit of protecting the factory lower control arms from potential trail damage that can be experienced while off-road.

Tech Info:

OEM Wheels & Tires Fitment: Yes
Recommended Aftermarket Wheels: ICON Alloys | 17x8.5 with 4.75" Backspace / 0mm Offset
Recommended Aftermarket Tires: 33" x 11.50" (Larger tires may fit but fender trimming and modifications will be required.)
APPLICATION NOTE #17: THESE ARE STAND-ALONE KITS AND ARE NOT TO BE USED IN CONJUNCTION WITH ANY OTHER AFTERMARKET KITS
APPLICATION NOTE #55: SHOCKS ARE FULLY SERVICEABLE. COILOVER HEIGHTS INDICATED ARE FOR A STOCK EQUIPPED VEHICLE
APPLICATION NOTE #59: WELDING REQUIRED - LOWER CONTROL ARM
APPLICATION NOTE #95: DOES NOT WORK WITH TRD BIG BRAKE KIT
APPLICATION NOTE #117: NOT RECOMMENDED WITH REMOTE RESERVOIR COILOVER
Ships in multiple boxes

Features & Benefits

Drastically improves vehicle damping ability off-road
Increased vehicle stability on-road
Utilizes factory lower control arms
Maintains OE track width
Vehicle-specific tuned secondary shocks provide increased damping and oil volume
CDC Valve technology allows for quick and easy compression damping adjustment
Shocks are fully rebuildable and revalveable
"Mostly bolt-on" design makes for straightforward install

System Components:

59706CP (QTY: 1) | TOYOTA S2 SECONDARY 2.5 RR CDCV PAIR
56102 (QTY: 1) | 07-UP FJ/03-UP 4RUNNER/05-UP TACOMA S2 SHOCK HOOP KIT
56107 (QTY: 1) | 16-UP TACOMA SKID PLATE KIT

Installation Instructions & Docs

Compatibility List

Year	Make	Model	Drive	Position	Lift
2023	Toyota	Tacoma			0-2.75"
2022	Toyota	Tacoma			0-2.75"
2021	Toyota	Tacoma			0-2.75"
2020	Toyota	Tacoma			0-2.75"
2019	Toyota	Tacoma			0-2.75"
2018	Toyota	Tacoma			0-2.75"
2017	Toyota	Tacoma			0-2.75"
2016	Toyota	Tacoma			0-2.75"

Product Details

Whether you want to upgrade, add a reservoir, or find something more affordable, contact us with any questions!

Part Numbers & Details

View full product specifications

Close specs

Part Numbers & Details

Specifications

Part Number	Lift/Lowered	Position	Item	Quantity
K53126	0-2.75" Lift	Front	S2 Secondary Shock System - Stage 2	1

Overview

Tech Info:

OEM Wheels & Tires Fitment: Yes
Recommended Aftermarket Wheels: ICON Alloys | 17x8.5 with 4.75" Backspace / 0mm Offset
Recommended Aftermarket Tires: 33" x 11.50" (Larger tires may fit but fender trimming and modifications will be required.)
APPLICATION NOTE #17: THESE ARE STAND-ALONE KITS AND ARE NOT TO BE USED IN CONJUNCTION WITH ANY OTHER AFTERMARKET KITS
APPLICATION NOTE #55: SHOCKS ARE FULLY SERVICEABLE. COILOVER HEIGHTS INDICATED ARE FOR A STOCK EQUIPPED VEHICLE
APPLICATION NOTE #59: WELDING REQUIRED - LOWER CONTROL ARM
APPLICATION NOTE #95: DOES NOT WORK WITH TRD BIG BRAKE KIT
APPLICATION NOTE #117: NOT RECOMMENDED WITH REMOTE RESERVOIR COILOVER
Ships in multiple boxes

Features & Benefits

Drastically improves vehicle damping ability off-road
Increased vehicle stability on-road
Utilizes factory lower control arms
Maintains OE track width
Vehicle-specific tuned secondary shocks provide increased damping and oil volume
CDC Valve technology allows for quick and easy compression damping adjustment
Shocks are fully rebuildable and revalveable
"Mostly bolt-on" design makes for straightforward install

System Components:

59706CP (QTY: 1) | TOYOTA S2 SECONDARY 2.5 RR CDCV PAIR
56102 (QTY: 1) | 07-UP FJ/03-UP 4RUNNER/05-UP TACOMA S2 SHOCK HOOP KIT
56107 (QTY: 1) | 16-UP TACOMA SKID PLATE KIT

Installation Instructions & Docs

Compatibility List

Year	Make	Model	Drive	Position	Lift
2023	Toyota	Tacoma			0-2.75"
2022	Toyota	Tacoma			0-2.75"
2021	Toyota	Tacoma			0-2.75"
2020	Toyota	Tacoma			0-2.75"
2019	Toyota	Tacoma			0-2.75"
2018	Toyota	Tacoma			0-2.75"
2017	Toyota	Tacoma			0-2.75"
2016	Toyota	Tacoma			0-2.75"
