1-3" Suspension System - Stage 1 Kit
Starting at $134/mo or 0% APR with Affirm. See if you qualify
Estimated Delivery in 3-7 business days
1-3" Suspension System - Stage 1 Kit
Starting at $134/mo or 0% APR with Affirm. See if you qualify
Estimated Delivery in 3-7 business days
Part Number | Lift/Lowered | Position | Item | Quantity |
---|---|---|---|---|
K73001 | 1-3" Lift | Front and Rear | 1-3" Suspension System - Stage 1 | 1 |
Overview
ICON Vehicle Dynamics 2007-2018 GM Silverado/Sierra 1500 suspension systems are designed to dramatically increase the on and off-road ride quality. ICON engineers'imary focus is to increase wheel travel and damping ability, which translates into outstanding vehicle control and ride quality both on and off-road. With wheel travel and ride quality in mind, ICON engineers researched each component of the GM platform'uspension and addressed any areas where performance could be extracted. The Stage 1 system includes vehicle-specific tuned 2.5 coilover shocks featuring an internal reservoir for exceptional cooling properties and ICON-engineered Eibach coil springs for superior vehicle "feel" through the range of travel. These coilovers are also height adjustable from 1-3" allowing the use of larger, more aggressive wheel and tire combinations. ICON 2.0 Aluminum Series monotube rear shocks utilize a vehicle-specific valving that balances the performance of the truck from front to rear. The ICON Vehicle Dynamics GM Silverado/Sierra 1500 Stage 1 suspension system is an excellent choice for those drivers looking to enhance the capabilities of their pickup on the road as well as in the dirt.
Tech Info:
- OEM Wheels & Tires Fitment: Yes
- Recommended Aftermarket Wheels: 17x8.5 with 5" Backspace / 6mm Offset
- Recommended Aftermarket Tires: 33" x 11.50" (Larger tires may fit but fender trimming and modifications will be required.)
- APPLICATION NOTE #55: SHOCKS ARE FULLY SERVICEABLE. COILOVER HEIGHTS INDICATED ARE FOR A STOCK EQUIPPED VEHICLE
- APPLICATION NOTE #83: TRIMMING OF THE UPPER CONTROL ARM STOP REQUIRED OR DOWN TRAVEL WILL BE LIMITED BY UPPER ARM STOP
- Ships in multiple boxes
Features & Benefits
- Fits 2WD and 4WD models
- Increased wheel travel and ride quality over stock with no change in towing capacity
- Vehicle specific tuned front and rear shocks for superior shock damping and control
- Adjustable coilovers from 1-3" of lift height
- 6061 Aircraft grade aluminum CNC machined components
- Corrosion resistant CAD plated coilover shock body with 7/8 shaft
- High strength alloy CNC machined lower bar pin
- FK rod end bearings for extended longevity and minimal deflection
- 2.0 Aluminum Series rear IFP shocks with 5/8" shock shafts
System Components:
- 71505 (QTY: 1) | 07-18 GM 1500 1-3" 2.5 VS IR COILOVER KIT
- 76526 (QTY: 2) | 07-UP GM 1500 0-2" REAR 2.0 VS IR
Installation Instructions & Docs
Year | Make | Model | Drive | Position | Lift |
2018 | GMC | Sierra 1500 | 4WD | 1-3" | |
2017 | GMC | Sierra 1500 | 4WD | 1-3" | |
2016 | GMC | Sierra 1500 | 4WD | 1-3" | |
2015 | GMC | Sierra 1500 | 4WD | 1-3" | |
2014 | GMC | Sierra 1500 | 4WD | 1-3" |
Product Details
Whether you want to upgrade, add a reservoir, or find something more affordable, contact us with any questions!
View full product specifications
View warranty coverage
Free shipping within the lower 48 United States
