0-2.75" Suspension System - Stage 1 Kit

2021-2024 Ford F-150 4WD

$2,079.85 $2,183.85

Starting at $130/mo or 0% APR with Affirm. See if you qualify

In Stock

Estimated Delivery in 3-7 business days

Icon

0-2.75" Suspension System - Stage 1 Kit

2021-2024 Ford F-150 4WD

$2,079.85 $2,183.85

Starting at $130/mo or 0% APR with Affirm. See if you qualify

In Stock

Estimated Delivery in 3-7 business days

Authorized dealer

Free shipping within the lower 48 United States

Brand new parts with warranty coverage

Free 30-day return and exchange on qualifying orders

Got Questions?

Our experts are here to help!

Chat now Request a call back

Part Numbers & Details

Specifications

Part Number	Lift/Lowered	Position	Item	Quantity
K93111	0-2.75" Lift	Front and Rear	0-2.75" Suspension System - Stage 1	1

Overview:

ICON Vehicle Dynamics 2021-UP Ford F-150 4WD suspension systems are designed with maximum performance and the serious driver in mind. ICON engineers' primary focus is to increase wheel travel and damping ability, which translates into outstanding vehicle control and ride quality both on and off-road. The Stage 1 system includes vehicle-specific tuned 2.5" coilover shocks featuring an internal reservoir for exceptional cooling properties and ICON-engineered Eibach coil springs for superior vehicle “feel" through the range of travel. These coilovers are also height adjustable from 0-2.75" allowing the use of larger, more aggressive wheel and tire combinations. ICON 2.0 Aluminum Series monotube rear shocks utilize a vehicle-specific valving that balances the performance of the truck from front to rear. The ICON Vehicle Dynamics 2021-UP F-150 4WD Stage 1 suspension system is an excellent choice for those drivers looking to enhance the capabilities of their pickup on the road as well as in the dirt.

Highlights:

Increased wheel travel and ride quality over stock with no change in towing capacity
2.0 aluminum body rear IFP shock with 5/8" polished shaft
100% Bolt-on system - no drilling, cutting, or welding necessary for install
Unique valving developed for the lighter weight of the 2021-UP F-150
Vehicle specific tuned front and rear shocks for superior damping and vehicle control
Adjustable coilovers from 0-2.75" of lift height
6061 Aircraft grade aluminum CNC machined components
Corrosion resistant CAD plated coilover shock body with 7/8" shaft
High strength alloy CNC machined lower bar pin
FK rod end bearings for extended longevity and minimal deflection

Fitment Notes:

OEM Wheels & Tires Fitment: Yes
Recommended Aftermarket Wheels: ICON Alloys | 17x8.5" w/ 5" Backspace / 6mm Offset
Recommended Aftermarket Wheels: ICON Alloys | 18x9" w/ 5.25" Backspace / 6mm Offset
Recommended Aftermarket Wheels: ICON Alloys | 20x9" w/ 5.625" Backspace / 16mm Offset
Recommended Aftermarket Tires: 33" x 11.50" (Larger tires may fit but fender trimming and modifications will be required.)
SHOCKS ARE FULLY SERVICEABLE. COILOVER HEIGHTS INDICATED ARE FOR A STOCK EQUIPPED VEHICLE
WILL NOT WORK WITH ELECTRONICALLY CONTROLLED SUSPENSION
F-150 Tremor trim lift height range 0-1.25" over stock
Ships in multiple boxes

Parts Contained:

91722 (QTY: 1) | 21-UP F150 4WD 0-2.75" 2.5 VS IR COILOVER KIT
96518 (QTY: 2) | 09-UP F150 2/4WD 04-08 F150 4WD REAR VS 2.0 IR

Compatibility List

Year	Make	Model	Drive	Position	Lift
2024	Ford	F-150	4WD		0-2.75"
2023	Ford	F-150	4WD		0-2.75"
2022	Ford	F-150	4WD		0-2.75"
2021	Ford	F-150	4WD		0-2.75"

Product Details
